USB 3.0 ExpressCard
Notebook extension card with 2 ports
Adds two Super Speed USB 3.0 ports to the notebook PC. The new USB 3.0 interface enables data transfer at 5 gigabits per second which is up to 10 times faster than USB 2.0!
The AK-EXCU3-01 Express Card adds two Super Speed USB 3.0 ports to the notebook PC. The new USB 3.0 interface enables data transfer at 5 gigabits per second which is up to 10 times faster than USB 2.0! Super Speed interface can save you a lot of valuable time as you no longer need to wait so long to complete data transfer especially those large files like HD movies or system backups. Furthermore USB 3.0 ports remain fully backwardly compatible with USB 2.0 devices providing you with excellent compatibility.
Built in jack power connector enables optional 5V power adapter connection to ensure enough power delivery for all types of power-hungry USB devices. True USB 3.0 support on both ports simultaneously brings your system up to speed with current and next-generation components and peripherals!
• Adds 2 USB 3.0 ports to notebook PC
• SuperSpeed data transfer
• Up to 10x faster than USB2.0
| Application | USB 3.0 notebook PC extension card |
|---|---|
| Designed for | Notebook PC with spare ExpressCard slot (34 or 54 mm) |
| Interface | ExpressCard (26pin) |
| Connectors | 2 x USB 3.0 (backwards compatible with USB 2.0) |
| Transfer rate | 5.0 Gbps (max) |
| DC input | 1.5V, 3.3V, 5V (from Express Card or optional 5V adapter) |
| Supported OS | Windows XP / Vista / 7 (32/64 bit) |
| Hot Swappable | Yes |
| Dimensions | 116 (L) x 40 (W) x 14 (H) mm |
| Product code | AK-EXCU3-01 |
